MAGIC Gamma Telescope — ABK team final project for ML

Headline model: Optuna-tuned XGBoost with sigmoid calibration, achieving TPR = 0.349 at FPR = 0.01 on the held-out test set (3,781 samples). Beats Random Forest, LightGBM, SVM-RBF, and a five-learner stacking ensemble on every low-FPR operating point.

Why XGBoost, not stacking? We initially proposed a stacking ensemble as the main model. End-to-end measurement (see Results section below and calibration_ablation.csv) showed that the LR meta-learner’s sigmoid output collapses resolution in the high-confidence tail — exactly where gamma-ray classification operates. Tuned XGBoost beats every stacking variant we tried.

Background: What Are We Looking At?

The MAGIC telescope detects Cherenkov radiation — flashes of blue light produced when gamma rays from deep space strike Earth’s atmosphere, creating cascading particle showers. The telescope’s camera captures an image of each shower, and a Principal Component Analysis reduces that image to an ellipse described by the 10 Hillas parameters in our dataset.

The fundamental task: gamma-ray showers (signal) and hadronic showers (background cosmic rays) both produce Cherenkov light, but their ellipse shapes differ because of the underlying physics. Gamma showers are electromagnetic — clean, narrow, and aligned toward the source. Hadronic showers involve nuclear interactions — messier, wider, and randomly oriented.

Our raw features describe this ellipse:

Engineered Features

All ratio features use an additive ε = 1e-3 to handle the 98 rows with fWidth = 0 and 5 rows with fAlpha = 0 that exist in the original UCI dataset. Heavy-tailed positive inputs (fLength, fWidth, fDist) and signed inputs (fAsym, fM3Long, fM3Trans) get log1p / signed-log1p applied to the raw copy before scaling. The engineered features themselves are computed from the unlogged originals so physical interpretation is preserved.

The implementation lives in src/feature_engineering.py (MagicFeatureEngineer).

Justification for Synthetic Data Generation

The Problem

The MAGIC dataset has ~12,330 gamma events and ~6,690 hadron events (~65%/35% split before dedup; 115 duplicate rows are removed first). The UCI documentation states: “For technical reasons, the number of h events is underestimated. In the real data, the h class represents the majority of the events.” The deployed telescope sees hadrons outnumber gammas roughly 10,000:1.

Two distinct problems hiding in this:

1. Training-set imbalance. Even at 65/35 the model has fewer hadron exemplars near the decision boundary, which hurts the classifier exactly where it matters. SMOTE addresses this.
2. Deployment-prior mismatch. The 10,000:1 production ratio is not corrected by reshaping the training set — adding a few thousand synthetic hadrons does not move you closer to 10,000:1, and trying to would dilute every SMOTE neighborhood. This is solved separately, by choosing the decision threshold on a calibrated probability so that the false-positive rate matches the operational tolerance (e.g., FPR = 0.01 means at most 1% of the 10,000 hadrons per gamma get through, which is what telescope operators actually care about).

Why Borderline-SMOTE is the right resampler here

1. The data is already simulation-adjacent

The Hillas parameters are statistical summaries of camera images produced by CORSIKA Monte Carlo simulations. Linearly interpolating between two simulated samples produces another point in the same simulated space — there is no “real photon trajectory” being violated.

2. All features are continuous

There are no categorical fields or discrete constraints that interpolation would break. The interpolated point represents a plausible intermediate shower (slightly different energy, impact parameter, or atmospheric depth).

3. Physical constraint validation

After generating synthetic samples we check:

• fLength > 0 (shower has positive length)
• fWidth ≥ 0 — relaxed from > 0 because 98 real samples have fWidth = 0 and would otherwise be rejected
• fLength ≥ fWidth (major axis ≥ minor axis by definition)
• 0 ≤ fConc ≤ 1 and 0 ≤ fConc1 ≤ 1 (bounded ratios)
• fConc ≥ fConc1 (two pixels ≥ one pixel)
• 0 ≤ fAlpha ≤ 90 (bounded angle)
• fDist > 0 (distance is positive)

src/feature_engineering.py::validate_physical_constraints returns the mask. 100% of the real data passes; synthetic samples that fail are dropped before they reach the model.

4. Borderline samples are exactly the ones we need

Borderline-SMOTE targets the decision boundary — samples that are hardest to classify. In physics terms these are ambiguous showers (e.g. a high-energy hadron that happens to produce a narrow, gamma-like cascade). Concentrating generation there gives the model new evidence at the interface where its errors live, instead of in dense interior regions.

Verification of the synthetic samples

The notebook performs all of these checks (see §10):

1. Distribution preservation — two-sample Kolmogorov–Smirnov test, feature-by-feature, between real hadrons and synthetic hadrons. High p-values mean we cannot reject identical-distribution.
2. Physical validity — every synthetic sample passes the constraints above.
3. No leakage — SMOTE is applied only inside fit() via imblearn.Pipeline, so it never touches validation or test data.
4. Correlation preservation — corr() on synthetic vs original.

Headline metric — why TPR at fixed FPR, not raw accuracy

Gamma-ray astronomy operates at the strict end of the ROC curve: you tolerate a small false-positive rate (1% – 10% hadron mis-ID) and ask how many real gamma events you keep. A classifier with higher ROC-AUC overall but worse efficiency at low FPR is worse for the actual task. The UCI dataset card calls this out explicitly:

“…a simple classification accuracy is not meaningful. One can use ROC analysis and the area below the curve, for instance, in the low FPR region.”

We therefore report, in order of importance:

1. TPR (gamma signal efficiency) at FPR ∈ {0.01, 0.05, 0.10} — primary headline.
2. Partial ROC-AUC restricted to FPR ≤ 0.2 — single-number summary of the region we care about.
3. ROC-AUC, PR-AUC, F1 — useful secondary diagnostics.

src/metrics.py::tpr_at_fpr and partial_auc implement these.

Headline model — Optuna-tuned XGBoost

The deployed model is XGBoost with Optuna-tuned hyperparameters wrapped in a single imblearn.Pipeline:

MagicFeatureEngineer  →  StandardScaler  →  Borderline-SMOTE  →  XGBoost (tuned)  →  sigmoid calibration on val

Why XGBoost won:

• Best TPR at every low-FPR operating point (see Results table). 0.349 at FPR=0.01, vs 0.215 for the best stacking variant.
• Fast. ~4 seconds to fit on the full training set (~11k rows after dedup) on a laptop CPU.
• Self-contained. No meta-learner, no extra calibration set complexity beyond the sigmoid wrapper.
• Interpretable. SHAP on the single XGBoost model produces feature-importance plots that map cleanly to physics (see notebook §9).

Pipeline steps

1. Load and dedup. Drop the 115 exact duplicate rows before splitting.
2. Stratified 60 / 20 / 20 split — train / validation / test. The test set is touched exactly once.
3. Physics-informed feature engineering (src/feature_engineering.py::MagicFeatureEngineer).
4. imblearn.Pipeline so Borderline-SMOTE runs only during fit, never on val/test.
5. Optuna tuning (25 TPE trials) on train → val, maximizing partial AUC ≤ 0.2. Tuned params persisted to best_xgb_params.json.
6. Sigmoid (Platt) calibration on the validation split so the threshold at FPR=0.01 is set against well-calibrated probabilities. Isotonic was tested and rejected — see below.
7. Test-set evaluation: efficiency table at FPR ∈ {0.01, 0.05, 0.10}, ROC, PR, calibration curve, SHAP.

Why sigmoid, not isotonic, for calibration

Direct measurement (see calibration_ablation.csv) showed that isotonic calibration on a 3,781-sample validation set destroys resolution at the high-confidence tail — TPR @ FPR = 0.01 dropped from 0.135 (uncalibrated stack) to 0.002 (isotonic-calibrated stack). Sigmoid (Platt) is monotone, so it preserves the ROC ordering exactly while still calibrating probability magnitudes for operating-point selection. Same applies to the XGBoost headline model.

Stacking ensemble — documented comparison

We also built a five-learner stacking ensemble (RF + tuned XGBoost + LightGBM + SVM-RBF + Logistic Regression, with an L2 Logistic Regression meta-learner) to test the hypothesis from the original proposal. It’s in magic_gamma_pipeline.ipynb and runs end-to-end. The empirical finding is in the Results table: the stack does not beat tuned XGBoost on the low-FPR region, because the LR meta-learner’s sigmoid squashes resolution exactly where the headline metric lives. Aggregate ROC-AUC is within 0.01, but TPR@FPR=0.01 is 38% lower. This is a real result and worth reporting; it’s why we ship XGBoost.

Results (test set, one run, seed = 42)

Numbers produced by python run_full.py on the held-out 3,781-row test set. Five base learners in the stack (RF, Optuna-tuned XGBoost, LightGBM, SVM-RBF, Logistic Regression); meta-learner is L2 Logistic Regression; sigmoid calibration is fit on the validation split. XGBoost is tuned by Optuna (25 TPE trials maximizing partial AUC ≤ 0.2 on validation). results.csv is the canonical output.

Plus the calibration ablation from calibration_ablation.py (older 4-learner stack, no Optuna), kept for the ROC-region story:

Three findings:

1. Optuna-tuned XGBoost is the strongest model on every operating point — this is the shipped model. Tuning lifted TPR @ FPR=0.01 from 0.339 → 0.349 over default-XGBoost. Best hyperparameters in best_xgb_params.json.
2. SVM-RBF is the weakest base learner, both standalone (0.252 at FPR=0.01) and as a stack contributor. Useful as a non-tree diversity signal in the comparison, not as a production model.
3. The stacking ensemble does not beat tuned XGBoost on the headline metric. Aggregate ROC-AUC for the stack (0.933) is within 0.01 of tuned XGBoost (0.942), but TPR @ FPR=0.01 is 38% lower (0.215 vs 0.349). The LR meta-learner’s sigmoid output squashes resolution exactly where the headline metric lives. Aggregate AUC hides this; the operating-point view doesn’t.

Shipped configuration: sigmoid-calibrated, Optuna-tuned XGBoost. The stack is retained in the codebase as a documented comparison and as a candidate for high-FPR operating points (≥ 0.1) where its diversity helps more than the sigmoid hurts.

Why this project is still relevant

The standard MAGIC analysis pipeline already uses Random Forest with Hillas parameters in production. Our contribution sits in four places:

1. Physics-informed feature engineering. Each engineered feature has a physical derivation rooted in Cherenkov shower physics (ellipticity, miss parameter, log-bright-pair, etc.), with ε-protected formulas so the 98 zero-width rows don’t break the pipeline.
2. Honest, leak-safe synthetic data generation. Borderline-SMOTE inside CV folds with post-hoc physical-constraint validation, and a KS test on synthetic vs real hadrons in the trained feature space.
3. The right headline metric for the actual task. Reporting TPR at fixed low FPR — the metric MAGIC operators actually care about — instead of aggregate ROC-AUC. Several published projects on this dataset report only aggregate AUC, which is misleading at the operating point.
4. An empirical finding worth reporting: that stacking with a sigmoid meta-learner does not dominate Optuna-tuned XGBoost on the low-FPR region of the MAGIC dataset. The instinct to default to stacking ensembles is widely held; we ran the experiment, measured carefully, and shipped the simpler model that actually wins.

Methodology diagrams

1. Overview

flowchart TD
    A[1. Receiving data and profiling<br/>19,020 rows, 10 Hillas params<br/>drop 115 duplicates → 18,905 rows]
    A --> B[2. Stratified 60/20/20 split<br/>train / val / test]
    B --> C[3. Feature engineering<br/>10 raw + 8 engineered = 18 features<br/>ε-safe ratios, log1p on heavy tails]
    C --> D[4. Borderline-SMOTE<br/>inside imblearn.Pipeline.fit only]
    D --> E[5. Optuna tuning of XGBoost<br/>25 TPE trials, maximize pAUC ≤ 0.2 on val]
    E --> F[6. Sigmoid calibration on val<br/>monotone, preserves ROC ordering]
    F --> G[7. Test-set evaluation<br/>TPR @ FPR ∈ 0.01 / 0.05 / 0.10 = headline<br/>ROC-AUC, PR-AUC, partial AUC as secondary]
    G --> H[8. Deployment<br/>FastAPI + Docker, MLflow registry]
    H --> I[9. Monitoring<br/>PSI on inputs, TPR decay on labeled holdout]
    I -.drift detected.-> E
    C -.stacking comparison<br/>(documented negative result).-> J[Stack: LGBM+XGB+RF+SVM+LR<br/>not deployed]

2. Feature Engineering Pipeline

flowchart TD
    R[Raw Hillas features 10<br/>fLength fWidth fSize fConc fConc1<br/>fAsym fM3Long fM3Trans fAlpha fDist]
    R --> L[Log transforms on raw copy<br/>log1p on fLength, fWidth, fDist<br/>signed log1p on fAsym, fM3Long, fM3Trans]
    R --> D[Physics-informed engineered features 8<br/>ellipticity = fLength / fWidth+ε<br/>shower_density = fSize / fLength·fWidth+ε<br/>miss_parameter = fDist · sin fAlpha<br/>concentration_ratio = fConc / fConc1+ε<br/>m3_magnitude = √M3Long²+M3Trans²<br/>log_bright_pair = fSize + log10 fConc+ε<br/>long_asym = fAsym / fLength+ε<br/>cos_alpha = cos fAlpha]
    L --> O[Concatenate → 18 features]
    D --> O
    O --> S[StandardScaler]
    S --> SM[Borderline-SMOTE on minority hadrons<br/>inside CV folds only]
    SM --> M[Model fit]

    V[Verification, not gating<br/>physical-constraint check on synthetic samples<br/>KS test: real vs synthetic hadrons<br/>see notebook §10] -.audit.-> SM

3. Production pipeline — tuned XGBoost

This is the shipped model. Single learner, single calibration step, single SHAP explainer — no meta-learner, no second calibration set.

flowchart TD
    A[Train data] --> B[MagicFeatureEngineer<br/>raw + 8 engineered features]
    B --> C[StandardScaler]
    C --> D[Borderline-SMOTE<br/>inside fit only]
    D --> E[XGBoost]
    O[Optuna TPE<br/>25 trials, maximize pAUC ≤ 0.2 on val] -.tunes.-> E
    E --> F[Sigmoid calibration<br/>on validation split]
    F --> G[Gamma / Hadron probability]
    G --> H[Decision threshold<br/>chosen at target FPR]

3a. Stacking ensemble — comparison study, not production

We built this to test the original proposal’s hypothesis that a stacking ensemble would outperform single learners. Empirically it does not (see Results table — TPR@FPR=0.01 = 0.215 vs 0.349 for tuned XGBoost). It’s kept in the codebase as honest reporting of a negative result. The original drawio diagram (diagram/model.drawio.png) had the HPO arrow flowing out of the prediction stage, which read as “predict then tune”. The corrected version below puts Optuna where it belongs — as a training-time loop around the base learners — and adds the preprocessing chain plus the sigmoid calibration step that the original omitted.

flowchart TD
    A[Train data] --> B[MagicFeatureEngineer<br/>raw + 8 engineered features]
    B --> C[StandardScaler]
    C --> D[Borderline-SMOTE<br/>inside CV folds only]
    D --> E1[RandomForest]
    D --> E2[XGBoost]
    D --> E3[LightGBM]
    D --> E4[SVM-RBF]
    D --> E5[LogReg]
    E1 & E2 & E3 & E4 & E5 --> F[Out-of-fold probability<br/>predictions, StratifiedKFold-5]
    F --> G[Meta-model: LogReg + L2]
    G --> H[Sigmoid calibration<br/>on validation split]
    H --> I[Gamma / Hadron probability]
    O[Optuna TPE search<br/>maximize pAUC ≤ 0.2 on val] -.tunes.-> E2

4. Deployment and Monitoring

What gets deployed is the tuned XGBoost pipeline (preprocessing + XGBoost + sigmoid calibration), serialized as a single artifact. Corrected version of the original diagram/mlops.drawio.png. The key changes from the original: the drift-response logic is split into three remediations (retrain / recalibrate sigmoid / re-pick threshold) rather than lumping them, the “ROC-AUC decay” performance probe is replaced with “TPR @ FPR=0.01 decay” to match the headline metric, and a labeled-holdout batch is made explicit as the source of ground truth that the performance probe depends on.

flowchart TD
    R[Model registry<br/>MLflow: tuned XGBoost + sigmoid] --> CI[CI/CD<br/>GitHub Actions]
    CI --> D[Docker container]
    D --> API[FastAPI<br/>inference endpoint]
    API -- predictions --> LOG[(Prediction log)]
    API -- raw inputs --> DRIFT[Input drift monitor<br/>PSI on Hillas params<br/>KS on engineered features]
    LH[(Labeled holdout batch<br/>MC-matched)] --> PERF[Performance monitor<br/>TPR @ FPR=0.01 decay]
    LOG --> PERF
    DRIFT -- PSI > 0.25 --> RETRAIN[Retrain XGBoost<br/>re-run Optuna]
    PERF  -- TPR drop --> RECAL_SIG[Re-fit sigmoid<br/>calibration on fresh val]
    PERF  -- threshold drift --> RECAL_THR[Re-pick threshold<br/>at target FPR]
    RETRAIN & RECAL_SIG & RECAL_THR --> ALERT[Alert / Redeploy]

Deployment & maintainability

• Containerized inference via FastAPI + Docker.
• Model versioning through MLflow.
• Drift detection: track Population Stability Index (PSI) on the 10 raw Hillas parameters plus the predicted-probability distribution. Trigger retraining at PSI > 0.25 (standard rule of thumb).
• Threshold recalibration on deployment. Whichever model we ship, its sigmoid-calibrated probability gets a fixed threshold chosen so that on a recent labeled batch the FPR matches the operational tolerance (typically 0.01–0.1).

AutoML

• Optuna (TPE sampler, 25 trials) tunes XGBoost on the train-fit / val-score loop, maximizing partial AUC ≤ 0.2. The test set is never touched. Best hyperparameters land in best_xgb_params.json.
• The stack uses the tuned XGBoost params for its XGB base learner. The other base learners use sensible defaults — tuning them all jointly is the next budget upgrade if you want to push the headline number further.
• SHAP is used for explanation, not feature selection — with only 18 raw+engineered features, automated SHAP-based pruning would risk dropping features whose value comes from interactions.

Repository layout

/
├── README.md                       # this file
├── magic_gamma_pipeline.ipynb      # full training / evaluation pipeline
├── build_notebook.py               # regenerates magic_gamma_pipeline.ipynb
├── src/
│   ├── feature_engineering.py      # MagicFeatureEngineer + constraint validator
│   └── metrics.py                  # tpr_at_fpr, partial_auc, efficiency_table
├── telescope_data.csv              # UCI MAGIC dataset
├── requirements.txt
├── run_full.py                     # full run: Optuna + baselines + stack
├── smoke_test.py                   # quick end-to-end check
├── calibration_ablation.py         # isotonic vs sigmoid vs passthrough A/B
├── server.py                       # FastAPI inference server
├── api_smoke.py                    # in-process API smoke test
├── monitoring.py                   # PSI / performance / calibration drift
├── Dockerfile                      # multi-stage serving image
├── .dockerignore
├── artifacts/                      # produced by run_full.py
│   ├── model_v1.joblib             # sigmoid-calibrated tuned XGBoost
│   └── deployment_config.json      # threshold + monitoring baselines
├── best_xgb_params.json            # Optuna-tuned XGBoost params (regenerated)
└── LICENSE.txt

How to run — training

pip install -r requirements.txt
python smoke_test.py                # plumbing check (~30s)
python run_full.py                  # Optuna + baselines + stack + artifact (~130s)
jupyter lab magic_gamma_pipeline.ipynb

run_full.py produces:

• artifacts/model_v1.joblib — sigmoid-calibrated tuned XGBoost, the deployable model
• artifacts/deployment_config.json — threshold (picked at val FPR=0.01), tuned params, monitoring baselines
• results.csv, results.json, best_xgb_params.json — comparison table & metadata
• mlruns/ — MLflow run with params, metrics, and the registered magic-gamma model (set MLFLOW_DISABLED=1 to skip)

Inspect the MLflow UI with mlflow ui --backend-store-uri ./mlruns.

How to run — serving

Option A: local uvicorn

pip install fastapi 'uvicorn[standard]' joblib
uvicorn server:app --port 8000

Then in another shell:

curl http://localhost:8000/health

curl -X POST http://localhost:8000/predict \
  -H 'Content-Type: application/json' \
  -d '{"fLength":28.8,"fWidth":16.0,"fSize":2.64,"fConc":0.39,"fConc1":0.20,
       "fAsym":27.7,"fM3Long":22.0,"fM3Trans":-8.2,"fAlpha":40.1,"fDist":81.9}'

Option B: Docker

docker build -t magic-gamma:v1 .
docker run --rm -p 8000:8000 magic-gamma:v1

Multi-stage image (~250 MB final), runs as a non-root user, ships its own healthcheck. The artifacts/ directory is baked in so the container is fully self-contained.

In-process API smoke test

python api_smoke.py

Uses fastapi.testclient to exercise every endpoint without starting uvicorn. Verifies happy-path predictions, batch endpoint, and that input validation correctly rejects out-of-range Hillas parameters.

How to run — monitoring

After deployment, check for drift against the reference training distribution:

# input-only drift (no production labels needed)
python monitoring.py --reference telescope_data.csv --current recent_batch.csv

# full check with labels — adds performance & calibration drift
python monitoring.py \
  --reference telescope_data.csv \
  --current   recent_batch.csv \
  --labels    recent_labels.csv

The script prints a per-feature PSI table; with labels, it also runs the TPR@FPR=0.01 decay check (baseline lives in deployment_config.json) and the Brier-score calibration check. Each monitor emits its own verdict: RETRAIN (input drift), REPICK_THRESHOLD (performance decay), or REFIT_SIGMOID (calibration drift). Matches the three-remediation flow in the Deployment & Monitoring diagram.

Tools Stack Summary
